LED Pool Light Replacement for Hayward ColorLogic and CrystaLogic 1.5 Inch

From $149.00

  • Drop-in LED pool light replacement with perma-seal housing for 1.5 inch nicheless fittings
  • LED pool light replacement for Hayward ColorLogic, 1.5 inch nicheless drop-in
  • Drop-in 1.5 inch nicheless LED pool light replacement for Pentair, Hayward, and Jandy
  • Hayward ColorLogic compatible 1.5 inch nicheless RGBW LED replacement pool light
  • 1.5 inch nicheless LED replacement pool light with soft-glow diffuser lens
  • Color-changing RGBW LED pool light replacement with 13 color modes
  • 1.5 inch nicheless RGBW LED pool light replacement with thin-jacket cable
  • Pool Lights Direct 1.5 inch nicheless RGBW LED replacement pool light, drop-in retrofit
  • Sealed 1.5 inch nicheless LED replacement pool light, 12VAC drop-in
  • 12VAC 1.5 inch nicheless LED pool light replacement, selectable 6W or 12W brightness
  • RGBW LED replacement pool light for 1.5 inch nicheless fittings
Brightness
Cable Length (ft)
Help Me Decide

Important! If you have multiple lights,you must replace all of them because the color change sequence will be different than the standard hayward. If you mix our lights with OEM hayward, they will not sync.

$149.00
$149.00 $599.00
Shipping calculated at checkout.

Color Sync

Our color changing program matches the Jandy (Z-Color) or Pentair (P-Color) color sequence. Simply set your hayward controller appropriately.

Perfect Fit

Our lights are threaded for the 1.5" female fitting that is used on Jandy watercolors and hydrocool lights.

2 Year Warranty

With our ultra durable design, we can offer double the warranty of the big brands.

Soft Glow Lens

To prevent hot spots, we use a special diffuser lens for even illumination.

Low stock

A drop-in LED replacement for Hayward ColorLogic and CrystaLogic pool and spa lights. This fits in the 1.5" conduit and uses cable tension and water pressure to keep it in place, rather than the expansion fitting like the original Hayward lights.

Choose your brightness and cable length at checkout. Select 6W for steps, benches, spas, and smaller pools, or 12W for medium size pools. Want even more brightness? Choose the 30W stainless steel (coming September 2026)

Then pick a 50, 100, or 150 ft cable to reach from your niche to the junction box. Between the two brightness levels and three cable lengths, there is a match across the ColorLogic 320, ColorLogic 160, and CrystaLogic lineup, in both the original and W3 part numbers.

ColorLogic 320 LACUS11100, LACUS11150, LMCUS11085, LMCUS11KIT

For Hayward SP0536 SP0537 Sp0538 wall fittings.

Coming soon! High output Stainless Steel model. This will be a 30W model that produces brightness nearly 30% more than the standard Hayward models. It will also have threaded connection in the back, and a thicker cable than normal to support the increased power. If interested, select that variation here and sign up for notifications as it will be released in September.

Built to outlast the original:

  • Soft glow diffuser for even lighting with no hot spots
  • Perma-seal housing engineered against the water intrusion that ends most pool lights
  • High-efficiency LED chipset that runs cool for years of operation
  • Liquid heat-transfer cooling for sustained brightness
  • Thin-jacket cable that pulls easily through tight conduit without binding (Plastic models only, Stainless Steel uses thick cable.)
  • 14 RGB color modes for vivid, programmable lighting (Not Hayward color programming) - you can choose Z-Color or P-Color light mode for your lights in the omnilogic controller.

Covered by a 2-year warranty against water intrusion and LED failure. Free US shipping.

Replaces these Hayward part numbers

ColorLogic 320 color: LACUS11030, LACUS11050, LACUS11100, LACUS11150, W3LACUS11030, W3LACUS11050, W3LACUS11100, W3LACUS11150, LACUN11030, LACUN11050, LACUN11100, W3LACUN11030, W3LACUN11050, W3LACUN11100. ColorLogic 160 color: LYCUS11030, LYCUS11050, LYCUS11100, LYCUS11150, W3LYCUS11030, W3LYCUS11050, W3LYCUS11100, W3LYCUS11150, LYCUN11030, LYCUN11050, LYCUN11100, W3LYCUN11030, W3LYCUN11050, W3LYCUN11100. CrystaLogic 320 white: LAWUS11030, LAWUS11050, LAWUS11100, LAWUS11150, W3LAWUS11030, W3LAWUS11050, W3LAWUS11100, W3LAWUS11150. CrystaLogic 160 white: LYWUS11030, LYWUS11050, LYWUS11100, LYWUS11150, W3LYWUS11030, W3LYWUS11050, W3LYWUS11100, W3LYWUS11150. Related accessories: LFGUY1000, LGGUY1000 niches, LKBUN1000 coupler, LTBUY11300 transformer.

Compatible Light Part Numbers

CrystaLogic 160

CrystaLogic 320

ColorLogic 160

ColorLogic 320

LACUS11100

LACUS11150

LMCUS11085

LMCUS11KIT

Specifications

Lumen Output (Brightness)

6W- 300 12W- 600

Cord Length (ft)

50/100/150 Selectable

Colors

RGBW (Others available with customization)

Warranty

2 Year Standard

Voltage

12 VAC

Light Sequence

Standard Jandy 14 Color

LED

SMD 3535 High Output

Power

6W/ 12W Selectable

Durability

IP68

Controller Options

These lights are 12VAC and can function with several methods to power them.

1. Existing Hayward Automation- you can use these if you set your controller to Z-Color or P-Color.

2. On/off switch- If using a standard on off light switch, the color sequence will change when you turn the lights on rapidly.

Download Installation Manual
LED Pool Light Replacement for Hayward ColorLogic and CrystaLogic 1.5 Inch

$149.00

1.5 Inch Nicheless Replacement LED Pool / Spa Light for Jandy Watercolors and Hydrocool

colorlogic sketch fitting

How do I know if it's compatible?

These lights have an expansion gasket fitting to secure the light into the PVC conduit. Ours do not use this feature, simply pull the cable during installation and the cable tension will keep our replacement lights in the tube.

Controller Setup

We send either Pentair style or Jandy style lights for the colorlogic and crystalogic applications. Simply choose the matching type in your omnilogic controller in the settings.

What's in the box?

  • LED Light

    We send the light in your specific power requirement.

  • Installation Tool

    We include a notched installation tool that will tighten to the light.

  • Gasket

    There is a round gasket that will be in the installation bag.

  • Attached Cable

    Your specified length cable will come atttached to the light.

Available Late 2026

Quick Connect Wire

This feature will be launched in December 2026. Current production uses normal wiring. We have engineered our lights to have a long life cycle, which is why we offer a lifetime warranty on everything.

However, as with any electronic item, there is a small chance of light fail prematurely. Many other LED light suppliers have the light permanently attached to the housing, so if you need to replace it, you would need to run new wires.

Our lights have a quick disconnect at the light- you don't need to replace the entire wire if our light fails.

Superior Brightness

High Output CREE LED

We use the highest grade LED's manufactured by CREE. Others use generic LED's which result in shorter life, lower output, and less radiant colors.

PLD SPECIAL FEATURES

COLORSYNC

Use your existing automation with the pentair or jandy program.

FROSTED LENS

No more blinding your pool guests

RESIN FILLED

For maximum durability, our electronics are sealed completely. Feel the difference.

Colorsync

You will receive either jandy or pentair programmed lights. Simply choose this option in your colorlogic controller.

Soft Diffuse Lens

No glare or hot spots on these lights. Just a smooth, even illumination of the pool

Resin Filled

Our lights are resin filled to prevent cracks and leaks. Competitors keep a hollow body that causes cracking and leaks over time.

Do you have a replacement light for me?

Most likely- yes! Call our client advisors during business hours for a recommendation.

How do I know what light I need?

Use our Light Finder to find the correct match. You can also text a photo of your light for a suggestion.

Why are your lights 1/3 the cost of the brand name version?

Brand name lights get sold from the factory to the OEM, then to the distributor or dealer, and then to the installer. Each step adds 30-50% to the price. By the time you have it installed, the price can be $500-$800 each. We sell direct to you to eliminate those markups.

Are your lights designed better?

Our goal is to

How are your lights controlled?

Each light has different control options- refer to the product page and there is a compatible controller section to describe how you can activate the lights.

Where are you based at?

Our headquarters is in Florida, and we ship worldwide.

What is your warranty?

Our warranty is 2 years, with optional extended warranties at checkout.

Why do the brand name lights fail after only 1-2 years?

The brand name lights use high power LED's with inadequate cooling and housing protection. Ours are designed to last longer.

What does Resin Filled mean and why is it better?

Low cost lights use a hollow design because its cheaper. This results in air pockets that constantly expand and contract with temperature. This flexing creates micro cracks in the housing that allows water to enter, shorting out the circuit. Our lights use resin to ensure there is no flexing of the material.

How long is shipping?

Our lights are made to order for now. In late 2026 we should have the warehouse stocked up for immediate shipment, but until then you should plan on 7-15 business days for shipping.

How do I install the lights?

We recommend you consult with a qualified pool tech to install. Some customers DIY install with youtube videos.

How long are your cables?

We offer various cable lengths to suit your application. Choose the best cable length at checkout. If you aren't sure, give us a call.
Designed in Florida.

Our lights are meticulously designed in the sunniest, harshest conditions to ensure your new lights will last for years.

Durability First.

Through extreme testing we can be confident of our designs lasting with exposure to constant use and chemical exposure.

Features that customers want.

We talk to pool owners and builders daily, so we can be sure of what the customers are needing on each revision.

  • All Patterns

    14

    Standard Jandy Color sequence

  • Efficient

    87%

    Energy savings

  • Up to

    600

    Lumen (brightness)
